2.7mm Galvanized Gabin Mesh For Riverside Protection

Short Description:

Basic Info Material: Galvanized Iron Wire Application: Gabion Mesh, Gabions, Construction Wire Mesh Hole Shape: Hexagonal Usage: Civil Engineering Technics: Woven Surface Treatment: Galvanized Size: 4m x 1m x 1m Aperture: 60*80mm Additional Info Packaging:  Plastic film then pallet or according to your requirements. Productivity: 800Sets per day Brand: FUHAI Transportation: Ocean,Land,Air Place of Origin: Hebei,China Supply Ability: 800Sets per day Certificate: ISO9001 HS Code: 7326209000 Por...


Product Detail

Product Tags

Basic Info

Material: Galvanized Iron Wire

Application: Gabion Mesh, Gabions, Construction Wire Mesh

Hole Shape: Hexagonal

Usage: Civil Engineering

Technics: Woven

Surface Treatment: Galvanized

Size: 4m x 1m x 1m

Aperture: 60*80mm

Additional Info

Packaging:  Plastic film then pallet or according to your requirements.

Productivity: 800Sets per day

Brand: FUHAI

Transportation: Ocean,Land,Air

Place of Origin: Hebei,China

Supply Ability: 800Sets per day

Certificate: ISO9001

HS Code: 7326209000

Port: Tianjin

Product Description

The Hexagonal Mesh Gabion Boxoriginated from bamboo Cages more than 2000 years ago in ancient China. Gabin Box is a new material widely used in transportation, water conservancy, municipal administration, gardens, soil and water conservation and other engineering projects in recent years. Galvanized Gabin Box .Gabin Wire Mesh has strong corrosion resistance. Gabin Wire Mesh.The twisted wire is twisted mechanically into multi-stranded and hexagonal mesh mesh. The length of twisted wire of Galvanized Gabin Box. Mesh should be no less than 5 cm, so as not to damage the protective coating of Steel Wire.

Purpose:

1. gabion retaining wall

2. River Gabion

3. Bridge protection gabion

4. Silo And Water Conservation Gabion

5. Home garden gabion

6. Hesco barrier

20161017080428632863774890



Details:



Table 1-Sizes for Gabion Box and Gabion Mattress
L (m) W (m) H (m) # of Cells
2 1 1 2
3 1 1 3
4 1 1 4
2 1 0.5 2
3 1 0.5 3
4 2 0.3 4
6 2 0.3 6
Table 2-Standard Mesh Wire
Mesh Type D (mm) Mesh Tolerance Mesh Wire (mm)
8×10 83 ±10% 2.70, 3.00mm
6×8 64 ±10% 2.20mm
Table 3-Standard Wire Diameters
Wire Diameter ø mm 2.2 2.7 3 3.4 3.8
Wire Tolerance (±) ø mm 0.1 0.1 0.1 0.1 0.1
Min. Qty of Zinc gr/m2 214 244 259 259 275

2702077754_2144736751

20140828163343_9954

000-tEvQoMIhuYzq



We offer our customers:

- Products of fine quality, favorable price and satisfactory post-sale service.

- Convenience to buy container loads of mixed products.

- Speedy delivery and standardized transportation service.

- Diversified trade terms such as Agency, International bidding, Counter trade, OEM, Assembling or Processing on supplied materials or designs.




Looking for ideal PVC Coted Gabin Mesh Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Gabin Mesh For Riverside Protection are quality guaranteed. We are China Origin Factory of Galvanized Gabin Box. If you have any question, please feel free to contact us.
